Weekly Timer Analogue Battery Backup Model: 134420 Hugo Muller

Weekly Analog Timer 230V – Din Rail Mounting

Make: Hugo Muller

Country of Origin: Germany



Download Catalogue – 134420 Series

Download Manual – 134420 Series

Description

  • Overview
    • Daily or Weekly Program
    • Slim format at 52.5 mm
    • Easy programming with captive setting keys
    • Easy to read switching program
    • Analogue Display (Clock Hands)
    • Manual override switch “Permanent OFF / Automatic / Permanent ON”



  • Technical Data
Supply voltages 230 V, 50-60 Hz
other voltages on request
Power consumption (real power) 0,4
Switch (potential-free) Change-over, contact gap < 3mm (µ)
Manual override switch Permanent ON / Permanent OFF / AUTO
Contact material AgSnO2
Switching capacity
resistive load:
inductive load:
16 A / 250 V~ at cosφ=1
2,5 A / 250 V~ at cosφ=0,6
Min. switching power 1.000 mW (10 V / 10 mA)
Filament Lamp, Halogen Lamp 2.000 W
Fluorescent Lamp uncopensated 1.000 W
Fluoresent Lamp series compensated 750 W
LED (230 V~) / CFL 200 W
Minimum switching interval
day dial:
week dial:
30 Min.
2 Std.
Time base Quartz
Accuracy (at 23°C) ≤±1 Sec./day
Power back-up (at 20°C) approx. 100 h.
Permitted ambient temperature –5°…+50°C
Housing self-extinguishing thermoplastic
Dimensions 45 x 52,5 x 55 mm
Mounting 35 mm DIN-rail and wall
Type of connection Screw terminals
Type of protection IP 20 to DIN EN 60529
Class of protection II when installed according to regulations
Mode of operation
(DIN EN 60730-1)
(DIN EN 60730-2-7)
1 BSTU
Degree of contamination
(DIN EN 60730-1)
2
Rated surge voltage
(DIN EN 60730-1)
4 kV
