H3D-M Multi Function Timer Analogue 12-240VAC/DC Anly

Multi Function Analogue TimerĀ

Make / Brand: Anly Electronics

Country of Origin: Taiwan



Download Catalogue – H3DM Series

Download Manual – H3DM Series

Shop Online

Description

  • Multi Function Timer Analogue Type – Din Rail Mounted
  • Operating Voltage: AC 24-240V ; DC 12-240V
  • Allowable Operating Voltage Range: 90-110% of rated operating voltage
  • Rated Frequency: 50/60Hz
  • Contact Rating: 250VAC 8A (resistive load)
  • Reset Time: MAX 0.1s
  • Power Consumption: Approx. 1.9VA
  • Time Range: 1s / 10s / 100s / 10m / 100m / 10h / 100h
  • Output Contact: 1C
  • Output Mode: 7 Mode
  • Standards: UL Listed, CE Certified
  • Dimension: (H)71.2mm x (W)17.5mm x (D)60mm
  • Weight: 62g
