3 Pin Micro Switch Short Lever Model: V15-187-01 Auspicious

Lever Push Type Micro Limit Switch 10A

Make: Auspicious

Country of Origin: Taiwan





Description

  • Lever Push Type
  • Range of Product: V15-187 Series
  • Rating: 10A 250VAC
  • Contacts Connection: One (1) Normally Open & Close Pin
  • Wire Cross-Section Area: 1.0-2.5mm
  • Disconnection Type: Micro Disconnection
  • Mounting Method: Built-In into an appliances
  • Rated Impulse Withstand Voltage: 2500V
  • Level of Glow-Wire Test: 3
  • Service Life: Mechanically: 1,000,000 operations min.
  • Service Life: Electrically: 100,000 operations min. (Full Load)
  • Standard Certification(s): TUV, CE Mark
