TAR5DE 1000A/1K0A Current Transformer – CT Revalco

CT – Current Transformer – Low Voltage – Busbarr 50x20mm

Make/Brand: Revalco

Country of Origin: Italy



Download Catalogue

Description

The CT makes it possible to measure high current values, and indicate, these using instruments of much lower rating.

  • Primary Current:
    * 1000A / 1K0A – Cable Max: 35mm
  • Horizontal Bar: 50 x 20 mm
  • Vertical Bar: 50 x 20 mm
  • Secondary Current: 5A AC
  • Accuracy Class: 0.5
  • Frequency: 50-60Hz
  • Dimensions: 100H x 82W x 40D mm
  • Approval: CE Mark
  • Weight: 420g
