ELR Relay Earth Leakage 30mA-30A Model: RDT30K Revalco

30A Din Rail Earth Leakage Relay – 3DIN Modules

Make/Brand: Revalco

Country of Origin: Italy



Download Catalogue

Shop Online

Description

  • Auxiliary Power Supply: 230V
  • Burden: 1.5W
  • Trip Current Adjustment:
    * 0.5 – 1 – 1.5 – 2 – 3 – 5 – 10 – 20 – 30 A
    * 30 – 100 – 300 mA
  • Time Delay Adjustment: 0…10sec
  • Output Pulse: NC – C – NO Relay 10A / 250VAC
  • Type AC
  • Protection Class:
    * IP20 on Terminals
    * IP40 on Front
  • Phase: Single-Phase
  • Module: 3 DIN Modules
  • Dimensions: 85H x 52.5W x 58D
  • Weight: 265g
