Description

The Current Transformer (CT) makes it possible to measure high current values, and indicate, these using instruments of much lower rating.

• Primary Current:
  * 40A – Cable Max: 20mm
  * 50A – Cable Max: 22mm
  * 60A – Cable Max: 30mm
  * 100A – Cable Max: 22mm
  * 150A – Cable Max: 22mm
  * 200A – Cable Max: 22mm
  * 300A – Cable Max: 22mm
  * 400A – Cable Max: 22mm
• Horizontal Bar: 30 x 10 mm
• Vertical Bar: 30 x 10 mm
• Secondary Current: 5A AC
• Accuracy Class: 0.5 5VA
• Frequency: 50-60Hz
• Dimensions: 80H x 61W x 59D mm
• Approval: CE Mark
• Weight: 325g
