Description

• Auxiliary Power Supply: AC/DC 90-270V
• Frequency: 50/60 Hz
• Power Consumption: 3VA
• Trip Current Adjustment:
  * 1 – 3 – 5 – 10 – 20 – 30 A
  * 30 – 100 – 300 – 500 mA
• Time Delay Adjustment: 0…10sec
• Output Pulse: 1 SPDT NO – NC Switch  (5A / 250VAC)
• Type A
• Protection Class:
  * IP20 on Terminals
  * IP40 on Front
• Module: 2 DIN Modules
